CCD Driver Board For Olympus GIF-H170 Endoscope

CCD Driver Board For Olympus GIF-H170 endoscope

► Brief Description

The Olympus GIF-H170's CCD Driver Board is an intricate piece of electronics that acts as the immediate interface and control unit for the image sensor. Its proper functioning is absolutely essential for the gastroscope to deliver the crisp, clear, and accurate HDTV images that are vital for diagnostic and therapeutic procedures.

► Features

• CCD Timing and Control
• Analog-to-Digital Conversion (ADC)
• Signal Pre-amplification and Conditioning
• Data Serialization and Transmission
• Color Information Processing

► Specification

►FAQ

What are the common signs of a defective CCD driver board in a GIF-H170?

• A: Typical indicators of failure include:

  • Complete absence of image feed ("No Signal" or blank screen on the monitor).

  • Intermittent video drops, screen flashing, or blackouts when bending or angulating the insertion tube.

  • Visual artifacts such as vertical/horizontal lines, static noise, pixel distortion, or incorrect color saturation.

  • Communication errors between the endoscope and the Olympus video processor (e.g., CV-170).

What are the primary causes of failure for this component?

• A: Major causes include:

  • Fluid Ingress: Leakage during automated washing, disinfection, or leakage testing that results in short-circuiting or corrosion.

  • Component Aging: Normal thermal and electrical degradation of surface-mount components over time.

  • Electrostatic Discharge (ESD): Handling internal components without proper grounding protocols during previous maintenance.

  • Mechanical Stress: Severe vibration or drops affecting the control handle housing.

► More service

Spare parts for flexible endoscope: insert tube, wires,helix tube,coil pipe,C-cover,glass for CCD,glass for light bundle,objective lens for CCD,drive board for CCD,light guide tube, light bundle,forcep tube, bending section, rubber, air&water tube, CCD, light source, processor, monitor, etc.
